ISO Diameter 18mm Black E Elastic Clips Black for Rail Fastening
- Product Number
- E Elastic Clips
- Quantity：
- 10000
- Rrice：
- ￥10000.00
- Time：
- 2015/5/22 11:47:41
Detailed Product Description
|
Product: |
E Elastic Clip |
Material: |
60Si2Mn, 60Si2MnA, 60Si2Cr, 60Si2CrA |
|
Color: |
Black |
Surface Treatment: |
Black Oxide |
|
Diameter: |
18mm |
ISO Diameter 18mm Black E Elastic Clips Black for Rail Fastening
About our factory:
Built in 2003, SUYU has been manufacturing E elastic clips. Most of our elastic clips are exported. Only some of them are sold domestically. Our E clip shows reliable quality after being used for so many years. There is no complaint from any of our customers.
(1) Material: the material is purchased from famous steel factory such as Shagang Group, Shougang Group.
(2) Research and development: we have our own R&D department. Many types of E clips can be custmized in our factory.
(3) The inspection center controls every process of production. Thus making sure E clip can meet customers' requirements.
(4) There are 20 senior technicians and 200 experienced workers in factory. With rich experience, they make high quality products to satisfy every customer.
General Specifications:
|
Name |
Hardness |
Fatigue Test |
Surface |
Standard refers |
|
E1809, E1817 elastic clip |
44-48HRC |
3 Million cycles without breaking |
Oxide black |
DIN17221, BS970, GB/T1222, UIC, ASTM |
Material Specifications:
|
Material |
60Si2MnA |
60Si2CrA |
55Si2Mn |
38Si7 |
|
Chemical composition(%) |
C:0.56-0.64 |
C:0.56-0.64 |
C:0.52-0.60 |
C:0.35-0.42 |
|
Mn:0.60-0.90 |
Mn:0.40-0.70 |
Mn:0.60-0.90 |
Mn:0.50-0.80 |
|
|
Si:1.60-2.00 |
Si:1.40-1.80 |
Si:1.50-2.00 |
Si:1.50-1.80 |
|
|
Cr:≤0.35 |
Cr:0.70-1.00 |
Cr:≤0.35 |
P:≤0.03 |
|
|
P:≤0.03 |
P:≤0.03 |
P:≤0.03 |
S:≤0.03 |
|
|
S:≤0.03 |
S:≤0.03 |
S:≤0.03 |
